THRU-HOLE CRYSTALS IN METAL PACKAGE

  Tuning Fork Crystals in 2.1 x 6.2 mm Cylindrical Package, 20 kHz - 192 kHz. XKC26
  HC-49/U Package, Wire Mount Type, 320 KHz - 1.024 MHz. HC49UW
  HC-49/U Package, 1.8432 MHz - 200 MHz. HC49U
  HC-51/U Package, 1.000 MHz - 4.200 MHz. HC51U
  HC-48/U Socket Pin Type, 1.000 MHz - 4.200 MHz. HC48U
  HC-49/US Low-Profile Package, 3.6 & 2.5 mm High, 3.5 & 8 MHz - 70 MHz. HC49S
HC49SS
  UM-1 Package, 8.0 mm High, Wire Mount Type, 800 KHz - 1.2288 MHz. UM1W

  UM-1 Package, 8.0 mm High, 3.6864 MHz - 225 MHz.

UM1
  UM-5 Package, 6.0 mm High, 10 MHz - 225 MHz. UM5
  3x9 mm, 3x10 mm Cylindrical Package, 3.579545 MHz - 70 MHz. CY309
CY310

SURFACE MOUNT CRYSTALS

  7 x 5 x 1.3 mm Ceramic Base Beam Welding Package, 4 Pads, 4 MHz - 15 MHz. XCB75
  7 x 5 x 1.3 mm Ceramic Base Seam Sealed Package, 4 Pads, 8 MHz - 150 MHz. XCS75
  6 x 3.5 x 1.1 mm Ceramic Base Seam Sealed Package, 4 Pads, 10 MHz - 150 MHz. XCS64
  5 x 3.2 x 1.4 mm Ceramic Base Glass Sealed Package, 2 Pads, 10 MHz - 54 MHz. XCR53
  5 x 3.2 x 1.0 mm Ceramic Base Seam Sealed Package, 4 Pads, 10 MHz - 250 MHz. XCS53
  4 x 2.5 x 0.8 mm Ceramic Base Seam Sealed Package, 4 Pads, 13 MHz - 32 MHz. XCS42
  3.2 x 2.5 x 0.7 mm Ceramic Base Seam Sealed Package, 4 Pads, 12 MHz - 156.25 MHz. XCS32
  2.5 x 2.0 x 0.65 mm Ceramic Base Seam Sealed Package, 4 Pads, 12 MHz - 80 MHz. XCS22
  2 x 1.6 x 0.45 mm Ceramic Base Seam Sealed Package, 4 Pads, 18 MHz - 60 MHz. XCS21
  11.8 x 5.5 x 1.5 mm Ceramic Base Resin Sealed Package, 4 Pads, 3.5 MHz - 30 MHz. XCR1
  HC-49/US SMD Package, 4.0 & 3.0 mm Height, 3.5 & 8 MHz - 70 MHz. HC49SM
HC49SSM
  HC-49/US 4 Soldering Pads SMD Package, 5.6 mm Height, 3.5 MHz - 70 MHz. HC494PD
  HC-49/U Formed Leads SMD Package, 1.8432 MHz  - 200 MHz. HC49USMD
  UM-1 Package with Metal Jacket and Formed Leads, 3.6864 MHz - 225 MHz. UM1SMD
  UM-5 Package with Metal Jacket and Formed Leads, 10 MHz - 225 MHz. UM5SMD

HIGH FREQUENCY FUNDAMENTAL CRYSTALS

  AT-cut Inverted Mesa Quartz Resonators, 50 MHz - 300 MHz. XHFF

32.768 kHz TUNING FORK WATCH CRYSTALS

  2 x 6 mm, 3 x 8 mm Thru-Hole Cylindrical Metal Package, 32.768 kHz. WXC26
WXC38
  4 Pad SMD Plastic Molded Package, 2.5 mm Height, 32.768 kHz, Compatible to Citizen CM200S and Epson MC-306. WXP2A
 32.768 kHz Watch Crystal in SMD-Cylinder Metal Package, Suitable for Solder Reflow Operation.  WXFSR
3.2 x 1.5 x 0.9 mm High Density Ceramic Package, Citizen CM315D, 32.768KHz. CM315D

HIGH STABILITY LOW COST CRYSTALS

  High Stability Crystals in HC49SM SMD Package, ±2.5 ppm/0°C to 50°C. HC49SM
  High Stability Crystals in HC49S Thru-hole Package, ±2.5 ppm/0°C to 50°C. HC49S

COTS CRYSTALS FOR MILITARY QPL SERIES

Military CR Types and Other Packages,  Manufactured and Tested per MIL-PRF-3098. COTS XTAL

Surface Mount Crystals Tape & Reel Specifications

Thru-Hole Crystals Tape & Reel Specifications

Handling Notes for Crystals
