SURFACE MOUNT TEMPERATURE COMPENSATED CRYSTAL OSCILLATORS

  High Frequency Sinewave TCXO in 19.8 x 12.5 x 5.2 mm SMD Package, 45 MHz - 190 MHz. TCLS2
  Clipped Sinewave TCXO/VC-TCXO in Standard Gullwing SMD Package, Low Phase Noise and Power Consumption, 8 MHz - 40 MHz. TCSS
  HCMOS/TTL TCXO/VC-TCXO in Standard Gullwing SMD Package, Low Phase Noise, 1.5 MHz - 40 MHz. TCSC
  Sinewave/Clipped Sinewave TCXO/VC-TCXO in 11.4 x 9.6 x 2.3 mm SMD Package, 10 MHz - 20 MHz. TCLS
   HCMOS/TTL TCXO/VC-TCXO in 11.4 x 9.6 x 2.3 mm SMD Package, Low Phase Noise, 1.25 MHz - 40 MHz. TCLC
  Clipped Sinewave TCXO/VC-TCXO in Ceramic Base 7 x 5 x 1.4 mm LCC Package, Tight Stability over Wide Temperature Range, 10 MHz  - 27.0 MHz. TC75A
  Clipped Sinewave TCXO/VC-TCXO in Ceramic Base 7 x 5 x 1.9 mm LCC Package, Tight Stability over Wide Temperature Range.  (Obsolete in 2022) TC75
  HCMOS TCXO in Ceramic Base 5 x 3.2 x 1.2 mm LCC Package, Tri-state Control with Low Standby current , 4 MHz  - 54 MHz. TC53C
  Clipped Sinewave TCXO/VC-TCXO in Ceramic Base 5 x 3.2 x 1.2 mm LCC Package, Tight Stability over Wide Temperature Range, 10 MHz  - 40 MHz. TC53A
  Stratum 3 TCXO/VC-TCXO in Ceramic Base 5 x 3.2 x 1.65 mm LCC Package, ±0.28ppm/-40°C to 85°C, HCMOS or Clipped Sinewave Output, 10 MHz - 52.0 MHz. TC53B
  Clipped Sinewave VC-TCXO in 3.2 x 2.5 x 1.0 mm Ultra Miniature SMD Package, 10.00 MHz - 52 MHz. TC32
  Clipped Sinewave VC-TCXO in 2.5 x 2.0 x 0.9 mm Ultra Miniature SMD Package, 10.00 MHz - 52 MHz. TC22
  Clipped Sinewave TCXO/VC-TCXO in 2.5 x 2.0 x 0.9 mm SMD Package, Tight Stability (0.5ppm) over Wide Temperature Range, 10 MHz  - 52 MHz. TC22A
  Clipped Sinewave TCXO/VC-TCXO in 2.5 x 2.0 x 0.9 mm Ultra Miniature Package, Standard Stability, 10 MHz  - 52 MHz. TC22B

THRU-HOLE TEMPERATURE COMPENSATED CRYSTAL OSCILLATORS

  Clipped Sinewave TCXO/VC-TCXO in 14 Pin Dip Package, Low Phase Noise and Power Consumption, 8 MHz - 40 MHz. TCTS
  HCMOS/TTL Compatible TCXO/VC-TCXO in 14 Pin Dip Package, Low Phase Noise, 1.5 MHz - 40 MHz. TCTC
  Pure or Clipped Sinewave TCXO/VC-TCXO in 14 Pin Dip Hermetically Sealed Package, Low Phase Noise and Power Consumption, 8 MHz - 40 MHz. TCHS
  HCMOS/TTL Compatible TCXO/VC-TCXO in 14 Pin Dip Hermetically Sealed Package, Low Phase Noise, 1.5 MHz - 40 MHz. TCHC

Surface Mount TCXOs Tape & Reel Specifications

For advanced TCXOs, please check our partner's product offering at www.valpeyfisher.com
