Micro-miniature Oven Controlled Crystal Oscillators

  Sinewave output with 50 Ohms load; Stratum3 or better stability (±0.1 ppm/-20 to 70°C); 14 Pin Dip metal package; 8 MHz - 100 MHz; Low cost. OC14S
  CMOS/TTL compatible square wave output; Stratum 3 or better stability (±0.1 ppm/-20 to 70°C); 14 Pin Dip metal package; 1 MHz - 100 MHz; Low cost. OC14C
  Low power consumption (0.15W at 25°C), Very fast warming-up; High stability (up to ±2 ppb); Low phase noise (-173 dBc/Hz at floor); 20.3x20.3x14.0 mm Dip metal package; CMOS/TTL or Sinewave output options; 8MHz - 150 MHz.  OCM37
  Low power consumption (0.15W at 25°C), Very fast warming-up; High stability (up to ±5 ppb); High frequency (multiplication by 3 or 5); 20.3x20.3x14.0 mm Dip metal package; CMOS/TTL or Sinewave output options; 30MHz - 300 MHz.  OCM37H
  Sinewave output with 50 Ohms load; Stratum3 or better stability (±0.1 ppm/-40 to 85°C); 20.3 x 20.3 x 10.5 mm Dip metal package; 4 MHz - 100 MHz. OC20S
  CMOS/TTL compatible square wave output; Stratum 3 or better stability (±0.1 ppm/-40 to 85°C); 20.3 x 20.3  x 10.5 mm Dip metal package; 1 MHz - 100 MHz. OC20C
  Sinewave output with 50 Ohms load; Stratum3 or better stability (±0.01 ppm/-20 to 70°C); 25.4 x 25.4 x 16 mm Dip metal package; 5V, 12V, 15V supply voltage available; 4 MHz - 100 MHz. OC25S
  CMOS/TTL compatible square wave output; Stratum 3 or better stability (±0.01 ppm/-20 to 70°C); 25.4 x 25.4  x 16 mm Dip metal package; 5V, 12V, 15V supply voltage available; 1 MHz - 100 MHz. OC25C
  Sinewave output with 50 Ohms load; Stratum3 or better stability (±0.01 ppm/-20 to 70°C); 36.2x27.2 x 16 mm Europack package; 5V, 12V, 15V supply voltage available; 4 MHz - 100 MHz. OC36S
  CMOS/TTL compatible square wave output; Stratum 3 or better stability (±0.01 ppm/-20 to 70°C); 36.2 x 27.2  x 16 mm Europack package; 5V, 12V, 15V supply voltage available; 1 MHz - 100 MHz. OC36C

For advanced OCXOs & Timing Modules, please check our partner at Valpey-Fisher Corp.
